BMW M5 Competition F90 LCI Facelift 2020 BMW Individual Imola Red three-quarter front view standing

THE M5

BMW M

BMW 5 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA

THE M5BMW 5 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA

The key facts and figures for the BMW 5 Series Sedan M Automobiles at a glance: find out all about engines, consumption, CO2 emissions and dimensions of the various BMW M5 models. Compare impressive performance data such as displacement, hp, Nm and acceleration – and discover which of these three exceptional sports sedans suits you best.

Citeşte în continuare

ENGINES AND TECHNICAL DATA OF THE BMW 5 SERIES SEDAN M AUTOMOBILES.

Select model

Weight

Unladen weight EU in kg 1,900
Max. permissible weight in kg 2,290
Permitted load in kg 465
Permitted axle load front/rear in kg 1,165/1,170
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 8/4
Capacity in ccm 4,395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 467 (635)/6,000
Engine torque (Nm) at 1/min 750/1,800-5,950
Compression ratio : 1 10.0

Performance

Top speed in km/h 305
Acceleration 0–100 km/h in s 3.0

Fuel consumption

Urban in l/100 km 14.7
Extra-urban in l/100 km 8.2
Combined in l/100 km 10.6
CO2 combined emissions in g/km 242
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 275/35 ZR20 (102 Y) XL
Tyre dimensions rear 285/35 ZR20 (104 Y) XL
Wheel dimensions and material front 9.5 J x 20 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 20 inches, light-alloy

Weight

Unladen weight EU in kg 1,970
Max. permissible weight in kg 2,440
Permitted load in kg 545
Permitted axle load front/rear in kg 1,215/1,260
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 8/4
Capacity in ccm 4,395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 460 (625)/6,000
Engine torque (Nm) at 1/min 750/1,800-5,860
Compression ratio : 1 10.0

Performance

Top speed in km/h 250 (305)
Acceleration 0–100 km/h in s 3.3

Fuel consumption

Urban in l/100 km 14.8
Extra-urban in l/100 km 8.2
Combined in l/100 km 10.6
CO2 combined emissions in g/km 243
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 275/35 ZR20 (102 Y) XL
Tyre dimensions rear 285/35 ZR20 (104 Y) XL
Wheel dimensions and material front 9.5 J x 20 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 20 inches, light-alloy

Weight

Unladen weight EU in kg 1,970
Max. permissible weight in kg 2,440
Permitted load in kg 545
Permitted axle load front/rear in kg 1,215/1,260
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 8/4
Capacity in ccm 4,395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 441 (600)/6,000
Engine torque (Nm) at 1/min 750/1,800-5,600
Compression ratio : 1 10.0

Performance

Top speed in km/h 250 (305)
Acceleration 0–100 km/h in s 3.4

Fuel consumption

Urban in l/100 km 14.8
Extra-urban in l/100 km 8.2
Combined in l/100 km 10.6
CO2 combined emissions in g/km 243
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 275/40 ZR19 (105 Y) XL
Tyre dimensions rear 285/40 ZR19 (107 Y) XL
Wheel dimensions and material front 9.5 J x 19 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 19 inches, light-alloy

Weight

Unladen weight EU in kg 1,990
Max. permissible weight in kg 2,560
Permitted load in kg 645
Permitted axle load front/rear in kg 1,260/1,365
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 8/4
Capacity in ccm 4.395
Stroke/bore in mm 88.3/89.0
Engine power in kW (hp) at 1/min 390 (530)/5,500-6,000
Engine torque (Nm) at 1/min 750/1,800-4,600
Compression ratio : 1 10.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.8

Fuel consumption

Urban in l/100 km 14.9
Extra-urban in l/100 km 8.3
Combined in l/100 km 10.7
CO2 combined emissions in g/km 246
Tank capacity, approx. in l 68

Wheels

Tyre dimensions front 245/40 R19 98 Y XL
Tyre dimensions rear 275/35 R19 100 Y XL
Wheel dimensions and material front 8 J x 19 inches, light-alloy
Wheel dimensions and material rear 9 J x 19 inches, light-alloy

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW M5 CS:
Fuel consumption in l/100 km (combined): 10.6
CO2 emissions in g/km (combined):242


BMW M5 Competition:
Fuel consumption in l/100 km (combined): 10.6
CO2 emissions in g/km (combined): 243


BMW M5:
Fuel consumption in l/100 km (combined): 10.6
CO2 emissions in g/km (combined): 243


BMW M550i xDrive Sedan:
Fuel consumption in l/100 km (combined): 10.7
CO2 emissions in g/km (combined): 246


The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.


The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.


For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.

Citeşte în continuare
​

Fuel consumption and CO2 emissions.

  • BMW M5 Competition:
    Fuel consumption in l/100 km (combined): 10.6
    CO2 emissions in g/km (combined): 243

    BMW M5:
    Fuel consumption in l/100 km (combined): 10.6
    CO2 emissions in g/km (combined): 243

    BMW M550i xDrive Sedan:
    Fuel consumption in l/100 km (combined): 10.7
    CO2 emissions in g/km (combined): 246

    Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.

    For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

    Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.

    The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission. Values in square brackets apply to vehicles with automatic transmission.

    [1] Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.

    [2] Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.

    For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp

    Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.

    [3] The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.
